สวิตช์ ควบคุมการหรี่ไฟ LED (สีเดียว) / Led Dimmer 12V 8A No-level Manual Dimming Controller for Single Color Led Strip
  • สวิตช์ ควบคุมการหรี่ไฟ LED (สีเดียว) / Led Dimmer 12V 8A No-level Manual Dimming Controller for Single Color Led Strip
  • สวิตช์ ควบคุมการหรี่ไฟ LED (สีเดียว) / Led Dimmer 12V 8A No-level Manual Dimming Controller for Single Color Led Strip
  • สวิตช์ ควบคุมการหรี่ไฟ LED (สีเดียว) / Led Dimmer 12V 8A No-level Manual Dimming Controller for Single Color Led Strip
  • สวิตช์ ควบคุมการหรี่ไฟ LED (สีเดียว) / Led Dimmer 12V 8A No-level Manual Dimming Controller for Single Color Led Strip
  • สวิตช์ ควบคุมการหรี่ไฟ LED (สีเดียว) / Led Dimmer 12V 8A No-level Manual Dimming Controller for Single Color Led Strip
  • สวิตช์ ควบคุมการหรี่ไฟ LED (สีเดียว) / Led Dimmer 12V 8A No-level Manual Dimming Controller for Single Color Led Strip

See larger image and other views (with zoom)

สวิตช์ ควบคุมการหรี่ไฟ LED (สีเดียว) / Led Dimmer 12V 8A No-level Manual Dimming Controller for Single Color Led Strip

   |   215 Transactions

รหัสสินค้า:LEDDM-CM-ZJT01

  • ราคา Unit : ฿ 166/pc   (ขอส่วนลดพิเศษ) (สินค้าถึงภายใน 14-20 วัน)

  • จำนวน: pc(s) Total Cost: ฿166
  • น้ำหนักการส่ง: 0.2lb (0.08kg) freightขนส่งสินค้า

  • Submit your order online to get membership points, a proforma invoice will be sent to you after you submit the order.
    Add to  Cart

Buyer Protection

สวิตช์ ควบคุมการหรี่ไฟ LED (สีเดียว)

สวิตส์ควบคุมการหรี่ไฟ  LED  สีสากล /สีเดียว ซึ่งสามารถหรี่แสงไฟ ให้สลั่วลงได้  ทุกๆระดับกระแสไฟฟ้า  12VDC หรือ 24VDC ,ผลิตภัณฑ์ LED  สำหรับใช้จังหว่ะในการปรับความกว้าง (PWM)สำหรับการควบคุมวงจร โดยลูกบิด จาก  0%-100%   โดยมีน็อตสกรูสำหรับการเชื่อมต่อขั้ว เพื่อเชื่อมต่อพลังงาน ทั้งนำเข้า รวมถึงส่งออก
สวิตซ์ควบควบคุมการหรี่ไฟนี้ สามารถปรับความสว่างได้อย่างไม่มีที่สิ้นสุด โดยโหมดควบคุมการทำงานของมันคือ  การควบคุมโดยลูกบิต ซึ่งคุณสามารถปรับความสว่าง ของแสงได้ตามที่คุณต้องการ
ข้อมูลเฉพาะ ทางเทคนิค:
การป้อนข้อมูล: DC12V
•เอาท์พุต: 1 ช่อง
•กระแสโหลดสูงสุด: 8A
•อุณหภูมิในการทำงาน: -20 ° C - 60 ° C
•มิติรูปลักษณ์ ภายนอกของสินค้า : ความยาว 89 ม.ม.*ความกว้าง * 60ม.ม.*ความสูง 53 ม.ม.
•วัสดุสินค้า: พลาสติก

การใช้งาน :
• สำหรับขั้นตอนแรก เชื่อมต่อสายส่งก่อน จากนั้นตามด้วย สายไฟ โปรดให้แน่ใจว่า  จะไม่เกิดกระแสไฟฟ้าลลัดวงจร รั่วไหล ในระหว่าง ที่คุณทำการเชื่อมต่อสายไฟ  ก่อนที่คุณจะทำการเปิดสวิตส์ไฟ
• ฟังก์ชั่น การทำงานของ สวิตซ์สำหรับหมุน ปรับระดับ หรี่ความสว่าง สามารถทำได้ดังต่อไปนี้
หมุนสวิตซ์ไปทางขวา แสงสว่างจะมีความสดใสขึ้น และหากเมื่อคุณหมุนสวิตซ์ไปทางด้านขวาจนสุด จะเกิดแสงสว่างมากที่สุด

ข้อมูลด้านความปลอดภัย
• 1. แรงดันไฟฟ้า ของผลิตภัณฑ์นี้คือ 12 โวลต์ DC (ไม่มากไปกว่านี้)
• 2.  กระแสไฟฟ้าที่ลัดวงจร ของสายไฟ จะนำมาซึ่งความเสียหาย ของสวิตส์ควบคุมการหรี่ไฟ
• 3.โปรดสังเกตุขั่วกระแสไฟฟ้าที่เหมาะสม เมื่อทำการเชื่อมต่อสายไฟฟ้า และสายส่ง อยู่เสมอ
• 4. สำหรับการ ใช้งานในร่ม ภายใต้อาคาร เท่านั้น (สินค้านี้ ไม่ได้กันน้ำ)





Led Dimmer 12V 8A No-level Manual Dimming Controller for Single Color Led Strip

CM-ZJ-T01 universal single color LED dimmer which can dim any 12VDC or 24VDC LED product from 0%-100% using a Pulse Width Modulation(PWM) circuit knob control. It has screw terminal connect for power in and out connections.

Dimmer is a controller that it can adjust brightness infinitely,its control mode is knob-operated control,you could adjust light to the appropriate lighting brightness in accordance with your actual need.

Technical Specifications:
•  Input: DC12V
•  Output: 1 channel
•  Max load current: 8A
•  Working Temperature: -20°C – 60 °C
•  External dimension: L89mm*W60mm*H53mm
•  Product Material: plastic

Direction for use:
•  Connect the load wire at first, following by the power wire: Please ensure short circuit can not occur between connecting wire before you turn on the power.
•  Adopt rotary button, its function as follows:
Rotate button to the right,brightness will be brighter,When you rotate it to the far right, the brightness is greatest.

Safety Information:

• 1. Supply voltage of this product is 12 Volts DC, do not exceed
• 2. Shorting output wires my cause damage to dimmer
• 3. Always observe proper polarity when connecting power and load
• 4. For indoor use only – this product is not waterproof or weatherproof
